Customized Control Cables from China Manufacturer

Taitong Cable is a professional manufacturer and supplier of a full range of electric wires and cables in China. Our control cables hold a leading position in the domestic market. As an influential control cable supplier, we are dedicated to providing global customers with high-quality and cost-effective cable products and services, and contributing to the development of the global power industry.

1. Product Overview and Applications

Taitong Control cables made in China are PVC-insulated and PVC-sheathed cables suitable for industrial and mining enterprises, energy and transportation departments, for control and protection circuits with AC rated voltage up to and including 450/750V, mainly used for transmitting control signals. They are typically applied in automation systems, machinery and equipment, electromechanical instruments, and industrial control systems, responsible for transmitting various signals from the control center to machines or equipment to ensure accurate and reliable operation.

2. Technical Parameters and Performance Features of Control Cables

2.1 Technical Parameters

Rated voltage: U0/U 450/750V

Long-term operating temperature of conductor cores: 70℃ and 95℃

Cable laying temperature: not lower than 0℃

Recommended minimum bending radius:

Non-armoured cable: not less than 6 times the outer diameter of the cable

Armoured or copper tape shielded cable: not less than 12 times the outer diameter of the cable

Shielded flexible control cable: not less than 6 times the outer diameter of the cable

Control cables are generally used for equipment instrument power supply and signal control.

2.2 Product Description

2.2.1 Executive standard: GB/T 9330-2008. Flame retardant cables shall also meet the technical requirements of IEC 337-8.

2.2.2 Performance Characteristics

DC resistance (at 20℃):

0.4mm copper conductor: ≤ 148 Ω/km

0.5mm copper conductor: ≤ 95 Ω/km

2.2.3 Dielectric strength:

Between conductors: 1kV for 1min, no breakdown

Between conductor and shield: 3kV for 1min, no breakdown

2.2.4 Insulation resistance:

Control cable: ＞ 10000 MΩ·km

HYAT cable: ＞ 3000 MΩ·km

2.2.5 Working capacitance: average 52±2 nF/km

2.2.6 Far-end crosstalk immunity: average power of specified combination at 150kHz ＞ 69dB/km

2.3 Material

Control cables adopt copper conductors.

Nominal cross-section 2.5mm² and below: 2–61 cores

4–6mm²: 2–14 cores

10mm²: 2–10 cores

2.4 Operating temperature:

Rubber insulation: 65℃

PVC insulation: 70℃ and 105℃

Control cables for computer systems usually use PVC, PE, XLPE or fluoroplastic insulation.

3. Types of Control Cables and Industrial Applications

Control Cable Type	Industrial Applications
Multi-core Control Cable	Automation equipment, mechanical control systems, electrical instrument connection.
Shielded Control Cable	CNC machine tools, robot systems, precision instruments, elevator control systems.
Oil-resistant Control Cable	Machine tools, industrial machinery, automobile production lines.
Flexible Control Cable	Frequently moving equipment, drag chain systems, automation equipment.
High-temperature Control Cable	Equipment in high-temperature environments, industrial furnaces, heat treatment equipment.
LSZH Control Cable	Subways, airports, hospitals, data centers and other high-safety places.
PVC Control Cable	General industrial automation, electrical control systems, building automation.
PE Control Cable	Outdoor control systems requiring anti-aging and UV resistance.
Waterproof Control Cable	Water treatment plants, ships, marine engineering.
Cold-resistant Control Cable	Cold storage, outdoor control systems in cold regions.
Drag Chain Control Cable	Drag chain systems and automatic production lines requiring frequent bending and movement.
Shielded Multi-core Control Cable	Control systems and data transmission with high anti-interference requirements.
UV-resistant Control Cable	Outdoor control systems requiring long-term exposure to sunlight.
Single-core Control Cable	Single control signal transmission, internal connection of electronic equipment.
XLPE Control Cable	Industrial control systems requiring high temperature resistance.

4. Company Strength and Service

Taitong Cable Co., Ltd. has more than 20 years of experience in wire and cable production and sales, and is a leading Grade A cable enterprise in China. Our control cables are widely recognized by customers for factory direct price and excellent quality. We provide customized cables in accordance with relevant standards based on customer requirements around the world. Taitong Cable take customers’ benefits as our responsibility, uphold the concept of global environmental protection, and provide reliable cable solutions for customers worldwide.Taitong Cable is striving to become a world-class cable supplier from China.

View as

Shielded control anti-interference cables

Taitong Cable is a large-scale and creative manufacturer and supplier of control cables in China. The great advantages of our Shielded control anti-interference cables with anti-interference performance is factory-made with competitive price and best quality for our customers. Taitong is proud to turn Chinese cable manufacturing into a global brand and cooperate with industry leaders worldwide.

View More >> Send Inquiry >>

Armoured control cables A or C Cables

Taitong Cable is a professional manufacturer of civil, industrial and special wires and cables. As a professional producer and supplier of armored control cables, our Armoured control cables A or C Cables are sold across China and many countries in Asia, America, Africa and Europe. Focusing on product quality and customer service, Taitong adheres to the global concept of environmentally friendly products. With advanced production and testing equipment and a professional technical team, we hope to establish long-term, stable and friendly cooperative relations with more international customers.

View More >> Send Inquiry >>

Soft conductor flexible control cables

Taitong Cable Co., Ltd. is a professional global wire and cable manufacturer and supplier. Our Soft conductor flexible control cables enjoy a large market share in China and have been exported to all over the world. With advanced production equipment and an excellent technical team, Taitong provides customers with professional and reliable cable supply services. We own a full set of professional qualifications and patents, strictly controlling every production process to ensure stable and high-quality products for global customers.

View More >> Send Inquiry >>

Taitong Cable is a professional Control Cables manufacturer and supplier in China. We warmly welcome you to wholesale high quality products at competitive price from our factory.
